Vacuum Brazing Furnace System

Used for brazing glass, electronic parts, metal parts, etc.

The equipment adopts double-layer water cooling, electric lifting, bell-shaped vertical all-stainless steel structure, three-zone Y-type heating, water-cooled all-metal heat insulation screen, automatic temperature control, and can be fully controlled by computer.

Technical parameters:

model		VBF -550
Vacuum Chamber		Bell cover vertical structure, size Φ550x700mm
Vacuum system configuration		Mechanical pump, molecular pump, gate valve
Ultimate pressure		≤1x10 ^-5Pa (after baking and degassing)
Thermal vacuum		850℃, up to 3.0x10 ^-4Pa
Restore vacuum time		6.6x10 ^-4Pa can be reached in 30 minutes (after short exposure to the atmosphere and filling with dry nitrogen, the air is pumped out)
Workspace	Vertical heating zone	Size Ф300x350mm (H)
	Uniform temperature working area	Size Ф200x250mm (H )
	heating	Maximum heating temperature 1000℃
	Temperature uniformity	±5℃
Equipment area	Host	1000x1300mm ²
	Electric control cabinet	700x700mm ²(two)
